Nrhiav rau siab - zoo galvanized steel phaj rau khoom siv hauv tsev? Koj twb nrhiav tau tus khub zoo. Raws li ib tug neeg muab khoom steel ntseeg siab, GNEE Steel muab zaub mov-qib thiab corrosion-resistantgalvanized steel phajhaum rau kev tsim khoom siv hauv tsev. Hauv phau ntawv qhia no, peb yuav piav qhia tias vim li cas peb cov khoom yog qhov kev xaiv zoo tshaj plaws rau cov tub yees, tshuab ntxhua khaub ncaws, thiab lwm yam khoom siv, ntxiv rau kev qhia cov ntsiab lus thiab kev txiav txim.
Galvanized steel phaj
Galvanized steel daim hlau yog cov ntawv hlau nrog zinc txheej uas sib txuas lub zog thiab xeb tsis kam. Rau cov khoom siv hauv tsev, lawv xav tau cov khoom siv ntxiv-zoo li cov npoo du, qhov ntev, thiab tsis yog - cov coatings coatings - kom ua tau raws li cov qauv kev nyab xeeb thiab zoo nkauj.
Feem ntau siv qib rau cov khoom siv hauv tsev muaj xws li DX51D + Z thiab DX53D + Z, uas muaj cov qauv zoo heev rau kev tsim cov khoom siv hauv lub plhaub, cov khoom siv sab hauv, thiab cov khoom siv.
Cov yam ntxwv tseem ceeb ntawm GNEE Steel's Galvanized Steel Phaj rau Cov Khoom Siv Hauv Tsev
Peb cov galvanized steel phaj rau cov khoom siv hauv tsev muaj cov yam ntxwv tshwj xeeb uas ua tau raws li kev lag luam xav tau:
- Smooth nto tiav: Nrog rau qhov roughness (Ra) tsawg dua los yog sib npaug li 1.6μm, peb cov phaj yog zoo meej rau kev pleev xim los yog laminating- kom ntseeg tau qhov tsis zoo ntawm cov khoom siv sab nrauv.
- Khoom noj khoom haus- txheej zoo: Cov zinc txheej tsis muaj cov hlau hnyav (Pb, Cd<10ppm), complying with FDA and EU food contact standards for fridge inner liners and washing machine drums.
- Zoo heev formability: Siab elongation tus nqi (Ntau dua lossis sib npaug li 28% rau DX51D + Z) tso cai rau kev kos duab sib sib zog nqus thiab nyuaj stamping - tseem ceeb rau kev tsim cov khoom siv xws li nkhaus qhov rooj fridge.
- Uniform thickness: Thickness sib txawv yog nyob rau hauv ± 0.03mm, kom ntseeg tau tias kev ua tau zoo ib yam thaum lub sij hawm stamping thiab zam cov khoom pov tseg.
- Cov roj tsawg: Cov ntsiab lus roj saum npoo yog tswj tau tsawg dua lossis sib npaug li 5mg / m², tiv thaiv kev sib kis ntawm cov khoom siv thiab ua kom muaj kev sib raug zoo rau kev ua haujlwm tom ntej.
Specifications ntawm Galvanized Steel Phaj rau cov khoom siv hauv tsev sib txawv
Cov khoom siv hauv tsev sib txawv yuav tsum tau tshwj xeeb galvanized steel phaj specifications. GNEE Steel muaj cov kev daws teeb meem rau txhua pawg:
| Yam khoom siv | Pom zoo Qib | Thickness Ntau | Txheej hnyav | Qhov Tseem Ceeb |
|---|---|---|---|---|
| Fridge plhaub | DX51D+Z | 0.4-0.8 hli | 60-80g/m² | Smooth nto, zoo xim adhesion |
| Fridge inner liners | DX53D+Z | 0.3-0.5 hli | 40-60g/m² | Khoom noj khoom haus- nyab xeeb, siab formability |
| Lub tshuab ntxhua khaub ncaws | S220GD + Z | 0.8-1.2 hli | 80-100g/m² | Corrosion tsis kam, cuam tshuam tsis kam |
| Qhov cub sab nrauv | DX52D+Z | 0.6-1.0 hli | 80-100g/m² | Thaum tshav kub kub kuj, khawb kuj |
| Cua txias casings | DX51D+Z | 0.5-0.7 hli | 60-80g/m² | Huab cua tsis kam, lub teeb yuag |
Peb kuj tuaj yeem kho qhov tsis xws li txheej thickness thiab nto tiav raws li koj cov khoom tsim tshwj xeeb.
Mechanical thiab Chemical Properties of Appliance-Qib Galvanized Steel Phaj
GNEE Steel's galvanized steel daim hlau rau cov khoom siv hauv tsev ua tau raws li cov qauv nruj thiab tshuaj lom neeg. Cov lus hauv qab no qhia txog cov khoom tseem ceeb:
-
Mechanical Properties
| Qib | Yield zog (MPa) | Tensile zog (MPa) | Elongation (%) | Hardness (HV) |
|---|---|---|---|---|
| DX51D+Z | Ntau dua lossis sib npaug rau 235 | 315-500 | Ntau dua lossis sib npaug li 28 | Tsawg dua los yog sib npaug li 140 |
| DX53D+Z | Ntau dua lossis sib npaug li 210 | 270-410 | Ntau dua lossis sib npaug li 34 | Tsawg dua los yog sib npaug li 130 |
| S220GD + Z | Ntau tshaj los yog sib npaug rau 220 | 330-450 | Ntau dua lossis sib npaug li 26 | Tsawg dua los yog sib npaug li 135 |
-
Tshuaj muaj pes tsawg leeg (DX51D + Z, %)
| Element | C | Mn | P | S | Si | Al |
|---|---|---|---|---|---|---|
| Cov ntsiab lus | Tsawg dua lossis sib npaug li 0.12 | Tsawg dua lossis sib npaug li 0.60 | Tsawg dua lossis sib npaug li 0.045 | Tsawg dua lossis sib npaug li 0.045 | Tsawg dua lossis sib npaug li 0.10 | Ntau dua lossis sib npaug li 0.02 |
Cov khoom no ua kom cov ntawv hlau tuaj yeem tiv taus cov kev ntxhov siab ntawm cov khoom siv sib dhos thiab kev siv txhua hnub -xws li rov qhib / kaw lub qhov rooj fridge lossis siab - kev sib hloov ceev ntawm lub tshuab ntxhua khaub ncaws.
Kev Tswj Xyuas Zoo thiab Ntawv Pov Thawj rau Cov Khoom Siv -Qib Galvanized Steel Phaj
Yuav kom ua tau raws li cov qauv kev lag luam hauv tsev, GNEE Steel siv kev tswj xyuas nruj:
- 100% nto tshuaj xyuas: Txhua lub phaj hlau galvanized raug kuaj xyuas qhov tsis xws luag xws li khawb, dents, lossis zinc spangles siv cov khoom siv kho qhov muag kho qhov muag.
- Txheej thickness kuaj: Sib nqus thickness gauges ntsuas txheej hnyav ntawm 5 ntsiab lus rau ib daim ntawv, kom ntseeg tau tias muaj kev sib haum xeeb.
- Kev xeem formability: Tsis tu ncua kev sib sib zog nqus nqus thiab dabtsi yog khoov kuaj xyuas cov hlau muaj peev xwm tiv taus cov txheej txheem tsim khoom.
- Tshuaj ntsuam xyuas: Spectrometers kuaj cov tshuaj muaj pes tsawg leeg ntawm txhua pawg los tiv thaiv cov khoom tsis zoo.
Peb cov galvanized steel phaj rau cov khoom siv hauv tsev tau txais ntau daim ntawv pov thawj:
ISO 9001 Kev Tswj Xyuas Zoo
FDA Daim Ntawv Pov Thawj Tiv Thaiv Khoom Noj
RoHS Ua Raws Cai (rau cov khoom siv hluav taws xob)
Daim ntawv pov thawj CE (rau EU lag luam)
Ordering and Delivery for Home Appliance manufacturers
GNEE Steel muaj kev hloov pauv hloov pauv rau cov khoom siv hauv tsev:
- Kev cai txiav: Peb muab kev txiav ncaj rau koj qhov loj me (txog 2000mm dav) txhawm rau txo koj ntawm - lub sijhawm ua haujlwm.
- Kev txiav txim loj thiab me me: Yam tsawg kawg nkaus txiav txim kom muaj nuj nqis yog 3 tons rau cov qib txheem, thiab 5 tons rau qib customized.
- Kev xa khoom sai: Lub sijhawm ua haujlwm yog 5-8 hnub rau cov khoom lag luam, thiab 10-12 hnub rau cov khoom lag luam customized.
- Qauv muaj: Cov qauv pub dawb (txog 5 nplooj ntawv) muaj rau kev sim ua ntej xaj ntau.
Tus nqi siv 2026 rau DX51D + Z (0.5mm thickness) yog $810-$850 ib tuj (ex-Factory). Rau kev txiav txim ntau tshaj 50 tons, peb muab 5-8% luv nqi.
GNEE Steelgalvanized steel phajyog qhov kev xaiv zoo tshaj plaws rau kev tsim khoom siv hauv tsev, nrog zaub mov- cov khoom muaj kev nyab xeeb, kev tsim tau zoo, thiab kev tswj xyuas nruj. Peb cov khoom ua tau raws li cov qauv siab tshaj plaws rau cov tub yees, tshuab ntxhua khaub ncaws, thiab lwm yam khoom siv, pab koj tsim cov khoom ruaj khov, siab - cov khoom zoo.
Yog tias koj yog ib lub chaw tsim khoom siv hauv tsev tab tom nrhiav kev txhim khu kev qha galvanized steel phaj lwm tus neeg, tsis txhob yig tiv tauj peb.Xa koj cov khoom siv tshwj xeeb rau GNEE Steel hnub no, thiab peb yuav muab cov kev daws teeb meem thiab cov lus sib tw!
