Nias -} xauv steel grating - sib xyaw, tseem ceeb, louver, hnyav
Tom qab grooving ntawm cov kabmob bar, tus ntoo khaub lig bar xovxwm tub xauv thiab moulded.
Qhov siab tshaj plaws tshuab hluav taws xob qhov siab ntawm cov steel grating yog 100 mm, qhov ntev ntawm steel grating yog tsawg dua 2000 mm.
Tus qauv siab ntawm cov kabmob bar: 20 hli rau 170 hli.
Cov qauv tuab ntawm cov kabmob bar: 2 hli, 3 hli, 4 hli, 5 hli.
| Cov Kab Npab Bar lub hli |
Hla Bar lub hli |
||||||||
|---|---|---|---|---|---|---|---|---|---|
| 11.1 | 11.1 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 | |
| 15 | 11.1 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 | |
| 21 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 22.2 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 33.3 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 44.4 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 55.5 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 66.6 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 99.9 | 11.1 | 16.65 | 21.0 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| Cov Kab Npab Bar lub hli |
Hla Bar lub hli |
||||||
|---|---|---|---|---|---|---|---|
| 21 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 25 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 33.3 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 50 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 66.6 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
| 99.9 | 16.65 | 22.2 | 33.3 | 44.4 | 49.95 | 66.6 | 99.9 |
- Hom sib xyaw
Cov kabmob bar ntawm kev sib txuas steel grating muaj qhov siab tib yam li hla bar. Lub grooving tob yog 1/2 ntawm cov kabmob bar.
Qhov siab ntawm cov steel grating yog tsawg dua 100 mm. Thiab qhov ntev feem ntau tsawg dua 2000 mm.
Tus qauv siab ntawm cov kabmob bar:20 hli mus rau 100 hli.
Tus qauv tuab ntawm cov kabmob bar:2 hli, 3 hli, 5 hli.
| Cov Kab Npab Bar lub hli |
Hla Bar lub hli |
||||
|---|---|---|---|---|---|
| 22.2 | 16.65 | 22.2 | 44.4 | 66.6 | |
| 33.3 | 16.65 | 22.2 | 33.3 | 66.6 | |
| 44.4 | 16.65 | 22.2 | 44.4 | ||
| 66.6 | 16.65 | 22.2 | 33.3 | 66.6 | |
| Cov Kab Npab Bar lub hli |
Hla Bar lub hli |
|||
|---|---|---|---|---|
| 33.3 | 16.65 | 33.3 | 66.6 | 99.9 |
| 66.6 | 16.65 | 33.3 | 66.6 | |
| 99.9 | 16.65 | 33.3 | 99.9 | |
Hnyav Plaub Ntug Kev Sib Tw
Hnyav plaub hau steel grating yog me ntsis los ntawm cov kabmob bar thiab hla bar nyob rau hauv lub 1200 tons nyob rau hauv lub zog moulding. Nws yog qhov haum rau cov khoom plig siab thauj khoom.
Tus qauv siab ntawm cov kabmob bar: 80 mm rau 200 hli.
Cov qauv tuab ntawm cov kabmob bar: 8 hli, 10 hli, 12 hli.
| Cov Kab Npab Bar lub hli |
Hla Bar lub hli |
||
|---|---|---|---|
| 25 | 50 | 75 | 100 |
| 50 | 50 | 75 | 100 |
| 75 | 50 | 75 | 100 |
| 100 | 50 | 75 | 100 |
- Louver Steel Grating
Cov kabmob bar ntawm louver steel grating qhib lub chute nrog 30℃lossis 45 degree. Tus ntoo khaub lig bar grooved thiab nias xauv.
Qhov siab grating yog tsawg dua 100 mm.
Tus qauv siab ntawm cov kabmob bar: 30 hli rau 100 hli.
Cov qauv tuab ntawm cov kabmob bar: 2 hli, 3 hli.
| Cov Kab Npab Bar lub hli |
Hla Bar lub hli |
|||
|---|---|---|---|---|
| 33.3 | 16.65 | 22.2 | 33.3 | 66.6 |
| 66.6 | 16.65 | 22.2 | 33.3 | 66.6 |
| 99.9 | 16.65 | 22.2 | 33.3 | 66.6 |
Nco tseg:Raws li cov cai yuav tsum sib txawv. Peb tuaj yeem tsim cov steel grating nrog lwm cov lus qhia tshwj xeeb thiab kev sib tw
