Cold Rolled Steel Phaj
Txias dov steel phaj plays lub luag haujlwm tseem ceeb hauv kev tsim khoom niaj hnub, tshwj xeeb tshaj yog nyob rau hauv kev lag luam uas xav tau qhov zoo ntawm qhov chaw, nruj qhov ntev ntev, thiab kev ua haujlwm ruaj khov. Ntawm cov feem ntau siv txias dov steel qib,DC01, DC03, DC04, DC05, DC06, thiab DC07txhais hauv qabTS EN 10130feem ntau yog xaiv rau cov ntawv thov xws li los ntawm cov qauv txheej txheem mus rau kev sib sib zog nqus- kos duab qhov chaw.
Cold Rolled Steel Phaj yog dab tsi?
Txias dov steel phaj yog tsim los ntawm kev ua kom kub dov hlau los ntawm kev txo qis hauv chav sov. Cov txheej txheem no txhim kho qhov chaw tiav, thickness raug, thiab txhua yam sib xws. Piv nrog rau cov kub dov hlau, cov qib txias dov muab cov npoo smoother, zoo dua flatness, thiab txhim kho formability, ua rau lawv zoo tagnrho rau precision stamping, dabtsi yog khoov, thiab kev ua haujlwm.
Txheej txheem cej luam ntawm DC01-DC07 Cold Rolled Steel Qib
DC series sawv cev tsis yog- alloy txias dov qis- cov qib carbon steel, feem ntau txawv los ntawm lawvtsim muaj peev xwm. Raws li tus lej qib nce los ntawm DC01 txog DC07, steel qhov sib sib zog nqus- kos duab kev ua tau zoo.
| Qib | Tsim Muaj Peev Xwm | Tej kev siv |
|---|---|---|
| dc01 ua | Kev tsim qauv yooj yim | Panels, brackets, general fabrication |
| dc03 ua | Txhim kho txoj kev tsim | Lub teeb stamping, cov khoom siv plhaub |
| dc04 ua | Daim duab sib sib zog nqus | Automotive puab qhov chaw |
| dc05 ua | Kev kos duab sib sib zog nqus | Complex stamped Cheebtsam |
| dc06 ua | Daim duab sib sib zog nqus tshwj xeeb | Precision automotive qhov chaw |
| dc07 ua | Ultra- kos duab tob | Advanced forming applications |
DC01 vs DC03 - Qhov txawv tseem ceeb
Ntawm txhua qib txias dov,DC01 thiab DC03yog qhov feem ntau sib piv vim lawv muaj dav thiab sib tshooj.
| Khoom | dc01 ua | dc03 ua |
|---|---|---|
| Yield zog (MPa) | Tsawg dua los yog sib npaug li 280 | Tsawg dua lossis sib npaug li 240 |
| Tensile zog (MPa) | 270–410 | 270–410 |
| Elongation (%) | Ntau dua lossis sib npaug li 28 | Ntau dua lossis sib npaug li 34 |
| Formability | Basic | Txhim kho |
| Hom kev siv | Pav qhov chaw | Teeb duab sib sib zog nqus |
DC01 txias dov steel phajyog haum rau yooj yim dabtsi yog khoov thiab tiaj tus txheej txheem, thaumDC03 txias dov steel phajmuab elongation zoo dua thiab txo kev pheej hmoo ntawm kev tawg thaum lub sij hawm stamping. Cov neeg tsim khoom tsim cov khoom siv hluav taws xob lossis cov khoom siv tsheb teeb pom kev zoo feem ntau hloov kho los ntawm DC01 mus rau DC03 txhawm rau txhim kho txoj kev ntseeg siab yam tsis muaj nqi nce ntxiv.
Thickness, dav, thiab khoom siv ntau yam
Txias dov steel phaj hauv DC qib yog feem ntau nkag rau hauv thicknesses los ntawm0.3mm txog 3.0mm, nrog widths mus txog1850 hli, muaj nyob rau hauv coils, nplooj ntawv, los yog txiav - mus rau - ntev daim hlau. Nto finishes xws lici tiav, ua roj, los yogqhuavyog xaiv tau raws li cov neeg siv khoom xav tau.
Daim ntawv thov thoob plaws kev lag luam
DC01-DC07 txias dov steel phaj yog dav siv hauv:
- Automotive lub cev thiab cov khoom siv sab hauv
- Cov khoom siv hauv tsev xws li tub yees thiab tshuab ntxhua khaub ncaws
- Hluav taws xob cov txee thiab tswj vaj huam sib luag
- Rooj tog thav duab thiab hlau enclosures
Vim li cas thiaj xaiv GNEE STEEL rau Cold Rolled Steel Phaj?
GNEE STEEL muab tag nrho cov khoom ntawm DC01, DC03, DC04, DC05, DC06, thiab DC07 txias dov steel daim hlau, nrog rau kev tswj kom ruaj khov, hloov pauv kev xaiv, thiab kev ntim khoom zoo. Ntxiv rau EN 10130 qib, GNEE STEEL tseem muab SPCC, SPCD, SPCE, thiab SAE 1006 txias dov hlau, ua rau cov neeg siv khoom tau txais ntau yam tshwj xeeb los ntawm ib tus neeg muag khoom ntseeg siab.
Yog tias koj tsis paub meej tias DC01 lossis DC03 txias dov steel phaj yog qhov zoo rau koj daim ntawv thov, GNEE STEEL pab pawg kws tshaj lij tau npaj los pab. Xa koj qhov kev nug hnub no kom tau txais cov lus pom zoo rau qib kev tshaj lij thiab tus nqi sib tw.
\
