DC05 vs DC03 txias dov hlau
Thaum sib pivDC05 vs DC03 txias dov hlau, qhov tseem ceeb kev txhawj xeeb rau engineers thiab buyers yog formability nyob rau hauv sib sib zog nqus daim duab thiab siab deformation tej yam kev mob. Ob qib yog txhais raws liTS EN 10130thiab dav siv nyob rau hauv precision manufacturing, tab sis lawv txawv heev nyob rau hauv mechanical cwj pwm thiab daim ntawv thov haum.
Nkag siab DC05 Cold Rolled Steel
DC05 txias dov steelyog qib siab -formability qib optimized rau kev sib sib zog nqus daim ntawv thov. Nws nthuav tawm cov elongation siab heev thiab tsis tshua muaj zog tawm los, ua kom cov khoom sib xyaw ua ke nrog qhov tsis xws luag. DC05 feem ntau yog xaiv rau siab - qhov tseeb tsheb qhov chaw, sib sib zog nqus-cov vaj tse, thiab cov khoom uas muaj qhov tseem ceeb stretching.
Txias Rolled Steel
Chemical Composition Overview
| Qib Steel | Cov pa roj carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) |
|---|---|---|---|---|
| dc03 ua | Tsawg dua lossis sib npaug li 0.10% | Tsawg dua lossis sib npaug li 0.45% | Tsawg dua lossis sib npaug li 0.025% | Tsawg dua lossis sib npaug li 0.025% |
| dc05 ua | Tsawg dua lossis sib npaug li 0.10% | Tsawg dua lossis sib npaug li 0.60% | Tsawg dua lossis sib npaug li 0.025% | Tsawg dua lossis sib npaug li 0.025% |
DC05 qhov dav me ntsis alloying ntau pab txhawb nws cov elongation zoo dua, ua rau nws tsim nyog rau kev ua haujlwm nyuaj dua.
Mechanical Property Comparison
| Khoom | dc03 ua | dc05 ua |
|---|---|---|
| Yield zog | Tsawg dua lossis sib npaug li 240 MPa | Tsawg dua lossis sib npaug li 220 MPa |
| Tensile zog | 270 - 370 MPa | 260-350 MPa |
| Elongation (A80) | Ntau dua lossis sib npaug li 28% | Ntau dua lossis sib npaug li 35% |
| Deep Drawing Muaj peev xwm | Zoo | Zoo heev |
Qhov siab dua elongation thiab qis tawm lub zog ntawm DC05 txhim kho nws txoj kev sib sib zog nqus nqus, tshwj xeeb tshaj yog rau cov khoom siv nrog qhov tseem ceeb ncab.
Formability thiab Application Differences
- DC03 txias dov steel: Muab tag nrho zoo formability thiab nto zoo rau nruab nrab txoj hauj lwm.
- DC05 txias dov steel: Tsim los rausiab sib sib zog nqus daim ntaub ntawv, xws li automotive lub cev panels nrog complex contours, sib sib zog nqus- kos brackets, thiab precision hlau qhov yuav tsum tau tsawg kawg nkaus springback.
DC05 feem ntau yog qhov kev xaiv zoo tshaj plaws hauv kev tsim khoom ib puag ncig uas cov khoom siv geometry xav tau ntau yam yas deformation.
Surface Quality thiab processing
Ob leeg DC03 thiab DC05 yog muaj raws litxias dov steel ntawvthiabtxias dov steel kaujnrog zoo sib xws nto finishes haum rau ntxiv ua, xws li painting los yog txheej. DC05 feem ntau yuav tsum tau ua tib zoo tuav vim nws cov khoom softer, tab sis nws zoo heev nto zoo txhawb siab - cov khoom kawg.
Tus nqi thiab ntau lawm cuam tshuam
DC05 feem ntau yog tus nqi siab dua DC03 vim nws qhov kev tsim kho kom zoo dua qub thiab kev tswj hwm ntau lawm. Txawm li cas los xij, rau daim ntawv thov sib sib zog nqus, DC05 tuaj yeem txo cov cuab yeej siv thiab ua kom muaj txiaj ntsig, muaj peev xwm txo qis tag nrho cov nqi tsim khoom.
Kev siv yam
- dc03 ua: Cov khoom siv vaj huam sib luag, nruab nrab daim duab kos tsheb qhov chaw, kev tsim khoom dav dav.
- dc05 ua: Kev sib sib zog nqus sib sib zog nqus- kos cov khoom siv hauv lub cev, precision hlau vaj tse, cov khoom yuav tsum tau elongation siab.
Vim li cas thiaj xaiv GNEE STEEL?
GNEE STEEL muab ntau yam ntawmtxias dov steel qib, suav nrogDC01, DC03, DC04, thiab DC05. Peb cov khoom raug tsim nrog nruj ua raws li cov qauv thoob ntiaj teb, kom ntseeg tau tias kev ua tau zoo thiab zoo.
Cov neeg siv khoom xaiv GNEE STEEL rau:
Cov khoom ruaj khov muab ncaj qha los ntawm lub hoobkas
Customizable thickness, dav, thiab nto tiav
Txhim khu kev qha export ntim thiab xa khoom
Kev txhawb nqa rau kev xaiv cov khoom siv thiab kev siv
📩 Hu rau GNEE STEEL tam sim norau cov kws tshaj lij kev taw qhia thiab cov lus sib tw ntawm DC03, DC04, lossis DC05 txias dov hlau.
